Performance Specifications 5
Cat. No. 01024514
Culligan HE 1.5 Carbon Filter & Progressive Flow Carbon Filter
HE CF 12 HE CF 14 HE CF 16 HE CF 21
Tank Size, in. [mm] 12x52 [305x1321] 14x47 [356x1194] 16x53 [406x1346] 21x62 [533x1575]
Pipe Size, in. [mm] 1.5 [38.1]
Temperature 33–120°F
Water Pressure 20–125 psi
Water Pressure (Canada Only) 20–90 psi
Electrical 24V/60 Hz/21.6 W
Installed Size (HxDxW, in.) 62x24x14 57x24x14 63x24x16 72x24x21
Clear height required above unit 52" 47" 53" 62"
Media Quantity, ft
3
[L] 2 [57] 3 [85] 3 [85] 6 [170]
Taste & Odor Removal, gpm@psi 4@1 5@1 7@1 12@2
lpm@kPa 15.1@6.9 18.9@6.9 26.5@6.9 45.4@13.8
Dechlorination, gpm@psi 8@1 11@2 14@2 24@8
lpm@kPa 30.3@6.9 41.6@13.8 53.0@13.8 90.8@55.2
Backwash Flow, gpm [lpm] 8 [30.3] 10 [37.9] 15 [56.8] 25 [94.6]
pH limitation 5–11
Regeneration Time 30 minutes
Culligan HE 1.5 Greensand Filter* & Progressive Flow Greensand Filter*
HE GF 12 HE GF 14 HE GF 16 HE GF 21
Tank Size, in. [mm] 12x52 [305x1321] 14x47 [356x1194] 16x53 [406x1346] 21x62 [533x1575]
Pipe Size, in. [mm] 1.5 [38.1]
Temperature 33–120°F
Water Pressure 20–125 psi
Water Pressure (Canada Only) 20–90 psi
Electrical 24V/60 Hz/21.6 W
Installed Size (HxDxW, in.) 62x24x14 57x24x14 63x24x16 72x24x21
Clear height required above unit 52" 47" 53" 62"
Media Quantity, lb. [kg] 180 [82] 205 [93] 280 [127] 615 [280]
Normal Service Flow, gpm@psi 8@3 11@3 14@4 24@8
lpm@kPa 30.3@20.7 41.6@20.7 50.3@27.6 90.8@55.2
Peak Service Flow, gpm@psi 12@5 16@6 21@6 36@13
lpm@kPa 45.4@34.5 60.6@41.4 79.5@41.4 136.3@89.6
Backwash Flow, gpm [lpm] 10 [38.1] 15 [56.8] 20 [75.7] 30 [113.6]
pH limitation 6–9.5
Regeneration Time 30 minutes
*Greensand filters are not WQA or IAMPO certified.
