MPX 8200 strapping and corner module | 5
Strap head
The surface below the strap head on a strapping module becomes hot during machine
operation. Avoid contact.
Burn hazard. Hot surface below strap head.
Do not touch.
Hingesonupper-front
access door
Hinges on the left and right side of the
upper-front access door on the strapping
module are pinch points. Keep hands
away from the hinges as the door is
opened and closed.
Hinges on each side of upper-front access door are pinch points
(see above).
Keephandsclear.
No. Item
1
Strap head location
2
Strap head
2
1
