CUMMINS ALLISON JetScan MPX 8200 User Manual

Conguring strap length and printing | JetScan
®
MPX 8200 strapping and corner module | 11
Conguringstraplengthandprinting
See the JetScan MPX 8200 operating instructions for complete information on
system setup.
Totightenorloosenstraplength, setbinlimits and set facing:
1. Press the Menu tab on the main-processing screen.
2. Press Setup on the Menu tab screen.
3. Press Configure Sort Modes and then press the desiredsortmodebutton to
prompt a Configure Sort Mode screen, as shown below.
4. Press the Limits tab to:
a. Tighten or loosen strap length, depending on note
condition. This is helpful when sorting notes of
different ages and quality (new brick vs. older/highly
used). Press + to increase strap length; press – to
decrease strap length. Strap length can be different
for each strapping module. To return all strap lengths
to factory settings, press Default.
Adjusting the strap length is a trial-and-error
process. Straps that are too tight may break. When
straps are too loose, documents may slip out when
the strap falls into or is removed from the collection bin.
3 strapping
modules
4a
4b
4c
4d
4
5a
5
4
-2
