4 | JetScan
®
MPX 8200 strapping and corner module | Strapping module diagram
Strapping module diagram
1
2
3
8
7
5
6
4
11
10
7
9
No. Item No. Item
1
Upper-front access door
(transport access door)
7
Lower paper-roll access door
2
Transport path
8
Paper roll
3
Note stacker No. 2 (left)
9
Printer ribbon cartridge
4
Note stacker No. 1 (right)
10
Collection bin No. 1 (right)
5
Strap head
11
Collection bin No. 2 (left)
6
Strapping section
