Diesel Engine Complete Engine
55
Flywheel
W
ARN
I
N
G
This component weighs 23 kg [50 lb] or more. To
avoid personal injury, use a hoist or get
assistance to lift this component.
W
ARN
I
N
G
The pilot is short, so the flywheel can come off
suddenly.
Remove the six capscrews, retaining plate, coupling,
and flywheel.
Flywheel Housing
W
ARN
I
N
G
This component weighs 23 kg [50 lb] or more. To
avoid personal injury, use a hoist or get
assistance to lift this component.
Remove the nine capscrews, rear oil seal, and
flywheel housing.
Remove the rear oil seal.
Block Water Heater
NOTE: Be sure the engine coolant has been
drained.
Disconnect the block heater electrical cord.
00900187
00900188
00900189
cs900wf
