TANDEM PULLING
If the amount of pulling force required to make a pull exceeds the load rating
for a single cable puller, two cable pullers may be used in tandem to make the
pull. See Figure 9 below. Be sure to use a separate rope and set of accessories
for each cable puller. Each set of rope and accessories should meet or exceed
each cable pullers maximum pulling force.
21
Figure 9
MAINTENANCE
Capstan
Replace the capstan if it is grooved more than 1/16” deep.
Lubrication
Front and Rear Drive Chains — Lubricate the inside of both drive chains every
20 hours of operation with 90 wt. gear oil.
Capstan Shaft, Rear Drive Shaft and Ratchet Pawl — Grease every 10 hours with a
good quality multi-purpose (M.P.) grease. These grease fittings are located on the
side of the cable puller.
See item #39 on Model 88 Cable Puller exploded view.
Inspection
Important: After the first 5 hours of operation remove the cover and
inspect both chain tensioners. Adjust as needed.
Front and Rear Chain Inspection — Every 40 hours of operation the front and rear
drive chains should be removed and inspected for excessive wear or binding.
Motor Brushes – Inspect the two motor brushes every 30 hours. Replace
if less than 3/8” long. Always replace both brushes at the same time.
Do NOT alter this cable puller. Doing so will void the warrant
. Guards and
our protection.
