CAUTION
CAUTION
CAUTION
Wear eye protection when operating cable puller.
Inspect all components of the pulling system before begin-
ning any cable pull. This includes the cable puller and any
accessories ( sheaves, swivels. etc. ) Replace any worn or
defective components.
Be careful during assembly and disassembly of the pulling
system components. Have control of components before
removing any pins.
7
IMPORTANT SAFETY INFORMATION continued . . .
SPECIFICATIONS — Model 88 Cable Puller
Model No. 88 Cable Puller
width – 20 1/2”
length – 24 3/4”
height – 16”
weight – 101 lbs. (includes two mounting chains)
maximum pulling force – 8,000 lbs.
speeds (approx.) no load – 16 ft/min.
4,000 lbs. – 9 ft/min.
6,000 lbs. – 7 ft/min.
motor – 120 volts AC, 60 hertz, 15 amps
FEATURES
• Heavy duty all welded unitized steel frame
• Permanently mounted force gauge allows operator to monitor the pulling force
• Circuit breaker on/off switch — helps protect motor
• Safety pawl on capstan sprocket to prevent reverse rotation
• Tapered capstan to help avoid rope overlap
• Simple design provides for easy maintenance — only one guard covers all
sprockets and chains
• Tailing rope safety roller for operator safety — lets operator stand out of the
direct line of tight pulling rope
• Three handles for carrying or positioning puller
• Simple electrical system for easy maintenance
