25
PARTS LIST – PART #88-44 CABLE PULLER MOTOR
ITEM # PARTS DESCRIPTION QTY PART #
100 ARMATURE BEARING – FRONT 1 88-44A
101 ARMATURE 1 88-44B
102 ARMATURE BEARING – REAR 1 88-44C
103 BELLEVILLE WASHER 8 88-44D
104 NUT 4 88-44E
105 LOCK WASHER 4 88-44F
106 MOTOR END PLATE 1 88-44G
107 GEAR BOX HOUSING 1 88-44H
108 FAN SCREEN 1 88-44I
109 THREADED STUD 4 88-44J
110 MIDDLE MOTOR HOUSING 1 88-44K
111 FIELD 1 88-44L
112 SCREW 2 88-44O
113 LOCK WASHER 2 88-44N
114 END CAP HOUSING 1 88-44P
115 BRUSH 2 88-44Q
116 BRUSH CAP 2 88-44R
117 SCREW 4 88-44S
118 SET SCREW 2 88-44T
119 BRUSH HOLDER 2 88-44U
120 MOTOR CORD 1 450-4
121 OUTPUT SHAFT GEAR ASSEMBLY 1 88-44W
122 2ND GEAR ASSEMBLY 1 88-44X
123 1ST GEAR ASSEMBLY 1 88-44Y
