PARTS LIST – MODEL 88 CABLE PULLER
ITEM # PARTS DESCRIPTION QTY PART #
1 PULLER HOUSING 1 88-53
2 CHAIN GUARD 1 88-32
3 FLAT HEAD SOCKET CAP SCREW 5 88-1
4 #60 SPROCKET 1 88-54
5 CAPSTAN SPROCKET BOLT 4 88-55
6 STAR LOCK WASHER 4 88-56
7 CAPSTAN 1 88-33
8 CAPSTAN BUSHING 1 88-57
9 SPACER – JACKSHAFT 1 88-58
10 CAPSTAN WASHER – STEEL 1 88-59
11 CAPSTAN BOLT 1 88-60
12 #60 CHAIN MASTER LINK 1 77-010
13 #60 CHAIN 1 88-61
14 #60 IDLER SPROCKET 1 88-62
15 #60 IDLER SPROCKET BUSHING 1 88-63
16 CHAIN TENSIONER ARM 2 88-64
17 TENSIONER ARM COTTER PIN 2 88-2
18 #40 CHAIN 1 88-65
19 #40 IDLER SPROCKET BUSHING 1 88-66
20 #40 IDLER SPROCKET 1 88-67
21 KEP NUT 4 88-68
22 MOUNTING CHAIN ASSEMBLY 2 88-21 L
23 #40 CHAIN MASTER LINK 1 77-032
24 #40 SPROCKET – MOTOR 1 88-69
25 MOTOR SHAFT RETAINING RING 1 88-25
26 JACKSHAFT & SPROCKET WELDMENT 1 88-19
27 JACKSHAFT PHENOLIC WASHER 2 88-70
28 ROLLER BEARING – JACKSHAFT 2 88-35
29 INNER RACE – JACKSHAFT 2 88-36
30 PAWL 1 88-27
31 PAWL SPRING 1 88-26
32 HEX NUT 3 88-71
33 SAFETY ROLLER 1 88-18
34 SOCKET HEAD SHOULDER BOLT 1 280-2D
35 POWER CORD 1 450-4
37 WASHER – PHENOLIC 1 88-37
38 BOLT 2 88-38
39 GREASE FITTING 3 88-39
40 HEAVY DUTY RETAINING RING 1 88-40
41 JACKSHAFT WASHER – STEEL 1 88-41
42 MOUNTING CHAIN HANDLE ASSEMBLY 2 88-42
44 PULLER MOTOR 1 88-44
45 PULLER FORCE GAUGE 1 88-17
46 COVER 1 88-46
47 CIRCUIT BREAKER SWITCH 1 88-47
48 SLOTTED PAN HEAD MACH. SCREW 2 88-31
49 COVER SCREW 4 77-004
50 GAUGE ASSEMBLY SCREW 3 88-50
51 STAR LOCK WASHER 4 88-51
52 FLAT WASHER 2 88-52
53 CAPSTAN SHAFT WASHER – PHENOLIC 2 88-48
54 BEARING SPACER 1 88-74
