4 — PROGRAMMABLE PARAMETERS
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 36
BATTERY SETUP.................................. p. 63
~ Keyswitch Voltage
Nominal Voltage
— BDI
~ Battery Current
~ Battery Power
— UNDERVOLTAGE CONTROLLER... p. 63
— User Undervoltage
— Kp UV
— Ki UV
— OVERVOLTAGE CONTROLLER..... p. 64
— User Overvoltage
— BDI SETUP.................................. p. 64
— Reset Volts Per Cell
— Full Volts Per Cell
— Empty Volts Per Cell
Discharge Time
— BDI Reset Percent
MAIN CONTACTOR............................. p. 65
— Main Enable
~ Main State
~ Keyswitch Voltage
~ Capacitor Voltage
— Pull In Voltage
Holding Voltage
— Battery Voltage Compensated
— Open Delay
Weld Check Enable
— Main DNC Check Enable
— Main DNC Runtime Threshold
— Precharge Enable
EM BRAKE CONTROL........................ p. 67
~ EM Brake State
EM Brake Type
Pull In Voltage
Holding Voltage
Battery Voltage Compensated
Set EM Brake On Fault
Zero Speed Threshold
Zero Speed Threshold Time
Position Hold Settling Time
Brake Set Time
Torque Release Time
Brake Release Time
Torque Preload Time
Torque Preload Enable
Save Torque Preload
Torque Preload Cancel Delay
— EM Brake Fault Motor Revs
EMERGENCY REVERSE (EMR) .............. p. 69
EMR Enable
~ EMR State
— EMR Forward Lock
EMR Dir Interlock
EMR Time Limit
EMR Speed
EMR Accel Rate
EMR Decel Rate
— EMR SUPERVISION......... p. 70
— EMR Supervision Enable
— Tolerance
— Ramp Delay
— Ramp Rate
INTERLOCK BRAKING......................... p. 71
— Interlock Brake Enable
— Decel Rate HS
— Decel Rate LS
— Interlock Brake Timeout
— Supervision Enable
— INTERLOCK BRAKING
SUPERVISION....................p. 72
— Tolerance
— Ramp Delay
— Ramp Rate
— Position Settling Limit
HYDRAULICS...................................... p. 74
— LIFT SETTINGS.....................p. 78
~ Lift Input
~ Mapped Lift Throttle
~ Lift Command
— Lift Min Input
— Lift Max Input
— Lift Map Shape
— Lift Offset
— Lift Limit Switch Source
— Lift Limit Switch Type
— Lift Battery Lockout
— LOWER SETTINGS................p. 79
~ Lower Input
~ Mapped Lower Throttle
~ Lower Command
— Lower Min Input
— Lower Max Input
— Lower Map Shape
— Lower Offset
— Lower Filter
LOAD HOLD VALVE SETTING.........p. 79
*cdev revision dependent
DUAL DRIVE....................................... p. 80
SEE Dual Drive manual
