ITEM # PART # DESCRIPTION
1 GEM-3 SATELLITE SERVER, 1-1/2 GAL.
2A* WC-821WDR
1,2,3
VALVE, DUMP LEFT 120V 12W W/INTERNAL
RESISTOR & DIODE
2B WC-853
4
VALVE, BREW DUMP LEFT 240V 12W GEM12D/
TP/TPC
3A WC-442
1,2,3
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
3B WC-446
4
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
4A* WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5A* WC-844-101
1,2,3
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
5B WC-844-102
4
VALVE, BY-PASS, 220V NON-ADJUS TABLE W/
RESTRICTOR (WC-2945)
6A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
6B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL WC-
820WDR,WC-821WDR, WC-844WDR (NEWER
UNITS)
7A WC-723
1,2,3
CONTROL MODULE, UCM 120V TP2S /TP2T
GEMSS/GEMTS
7B WC-728
4
CONTROL MODULE, UCM 220V TP2S/ TP2T/
GEMSS/GEMTS
8A* WC-39395
LABEL, UCM OVERLAY DUAL TWIN 3-BATCH
GEMTS CURTIS
8B* WC-39439
LABEL, UCM OVERLAY GEMTS TWIN 2-BATCH
CURTIS
8C* WC-39438
LABEL, UCM OVERLAY GEMTS TWIN 1-BATCH
CURTIS
9* WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
10* WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11* WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-39462 LABEL, BOTTOM PANEL GEMTS
13 WC-61392 COVER, FRONT GEMTS TALL
14 WC-726
2
TRANSFORMER, ISOL 240/480.5KVA 120/240
15A WC-37102
1,2,3
KIT, WARMER ELEMENT 100W 120V GEN USE
15B WC-973
4
ELEMENT, WARMER ASSY 100W 220V
16 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
17 WC-29044-101 SLEEVE, OVERFLOW
18* WC-2402P-P ELBOW, 3/8”FL x 3/8” NPT PLATED
19A* WC-847
1,2,3
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
19B WC-883
4
VALVE, INLET 2 GPM 240V 10W
20A* WC-820WDR
1,2,3
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
20B WC-854
4
VALVE, BREW DUMP RIGHT 240V 12W
GEM12D/TP/TPC
ITEM # PART # DESCRIPTION
21* WC-1501 FUSE, HOLDER ASSY W/5A FUSE
22A* WC-102
1
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22B WC-180
2,3
SWITCH, TOGGLE 3 PST 30A/250V
22C WC-103
4
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
23 WC-5421
COVER, TOP SS GEM-12D GEM-
612ILD,TL9002,312IL
24A* WC-3528
1,2,3
LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
24B WC-3500T
4
LEG, 4” ADJUSTABLE W/TIE DOWNS LEG, 4”
ADJUSTABLE W/TIE DOWNS
25* WC-1809-P
FAUCET, PS/HPS SERIES HOT WTR 1/2-20 UNF
AP/ALP
26* WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
27* WC-5231 COMPOUND, HEAT SINK 5OZ
28 WC-596K
4
KIT, NOISE FILTER EMI 250V/30A 1PH
29 WC-61674
BRACKET, BREWCONE ALIGNMENT USE ON
WC-37310
30A WC-13335
1
HARNESS ASSY, COMPLETE TP2T10/ GEMTS
FOR SOLID STATE RELAY (INCLUDES
TERMINAL BLOCK)
30B WC-13336
2
HARNESS ASSY, COMPLETE TP2T16 GEMTS
FOR SOLID STATE RELAY (INCLUDES
TERMINAL BLOCK)
30C WC-13337
3
HARNESS ASSY, COMPLETE TP2T19 GEMTS
FOR SOLID STATE RELAY (INCLUDES
TERMINAL BLOCK)
30D WC-13338
4
HARNESS ASSY, COMPLETE TP2T30 GEMTS
FOR SOLID STATE RELAY (INCLUDES
TERMINAL BLOCK)
31* WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
32 WC-1250
4
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END (NOT SHOWN)
33A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
33B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
34A WC-4213-P
a
NUT, 5/8 LOCK PLATED
34B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
35 WC-314 POWER BLOCK, 5 STATION
36 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
37 WC-4439 SCREW, 6-32x¼ PHIL PAN HD SS
38 WC-4412 SCREW, 10-32x3/16” PH PN HD MS SS
39 WC-4616
SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD
STAINLESS STEEL
40 WC-1806
SEAT CUP, SILICONE USE ON WC-1809
FAUCET
GEMTS - Main Chassis - Parts List
ILLUSTRATED PARTS LIST IP33
1
GEMTS10A1000,
2
GEMTS16A1000,
3
GEMTS19A1000,
4
GEMTS30A1000
GEMSS/GEMTS - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 051118D
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWK
older units.
b
Units built before 05/15/17.
5HFRPPHQGHGSDUWVWRVWRFN
