ILLUSTRATED PARTS LIST IP69
RU AUTOMATIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 031022C
ITEM # PART # DESCRIPTION USED ON
1 WC-1200 CORD, 14/3 SJTO 6’ BLK W/PLUG DOMESTIC 3 PHASE UNITS
2 WC-1408 GRIP, CORD 7/8” OD DOMESTIC 3 PHASE UNITS
3 WC-806 VALVE, 1/4” BRASS BALL ASSY EMERGENCY REFILL RU’S ALL RU UNITS
4A WC-53104 TUBE ASSY, 1/4x14.50 ER W/NUTS RU-150/300 RU-150, RU-300
4B WC-53105 TUBE ASSY, 1/4x17.00 ER W/NUTS RU-225/600 RU-225, RU-600
4C WC-53109 TUBE ASSY, 1/4” ER W/NUTS RU-1000 RU-1000
5A WC-2705 TEE, 1/4 X 1/4 FLARE X 3/8 NPT PLATED ALL RU UNITS
5B WC-2402P ELBOW, 3/8 FLARE x 3/8 NPT PLATED URN-300, URN-600, URN-1000
6A* WC-801 VALVE, INLET BRASS .50 GPM 120V 10W DOMESTIC RU UNITS
6B WC-858 VALVE, INLET BRASS .50 GPM 220V 10W EXPORT RU UNITS
6C WC-12019 VALVE, INLET 4GPM 120V URN-300, URN-600, URN-1000
7* WC-3700 KIT, INLET VALV REPAIR USE ON WC-801/801R/885/890/858 ALL RU UNITS
8 WC-813 FLOW WASHER, .5GPM .5” S45 ALL RU UNITS
9 WC-301 TERMINAL STRIP, 4-S OLDER RU UNITS
1
10A WC-37166 KIT, AIR PUMP DOMESTIC RU UNITS
10B WC-1009 PUMP, AGITATION 220V EXPORT RU UNITS
10C WC-1002 PUMP, AGITATION 120V W/TERMS URN-300, URN-600, URN-1000
11 WC-5843 BRACKET, AERATOR PUMP RU ALL RU UNITS
12 WC-3600 TEE, CONNECTOR 3/16 POLYPROPYLENE RU-150, RU-225
13A WC-3900 LABEL, INSTRUCTION PANEL RU-150 RU-150
1
13B WC-3901 LABEL, INSTRUCTION PANEL RU225 RU-225
1
13C WC-3902 LABEL, INSTRUCT’S PANEL CURTIS RU-300 RU-300
1
13D WC-3903 LABEL, INSTRUCT’S PANEL CURTIS RU-600 RU-600
1
13E WC-3904 LABEL, INSTRUCT’S PANEL CURTIS RU1000 RU-1000
1
13F WC-38570 LABEL, INSTRUCTION PANEL RU-150/RU-300 RU-150
2
, RU-300
2
13G WC-38571 LABEL, INSTRUCTION PANEL RU225/RU-600 RU-225
2
, RU-600
2
13H WC-38574 LABEL, INSTRUCTN PANEL RU1000 RU-1000
2
14 WC-2405 ELBOW, 1/2 FLARE x 1/2 NPT ALL RU UNITS
15 WC-2609 SWIVEL, 1/2” TUBE X 1/2 NPT ALL RU UNITS
16 WC-2504 ELBOW, 1/2 NPT X 1/2 NPT ALL RU UNITS
17A* WC-1037 PUMP, WATER W/FITTINGS 120VAC DOMESTIC RU UNITS
17B WC-1039 PUMP, WATER W/FITTING 220/240 VAC EXPORT RU UNITS
17C WC-1040-101 PUMP, WATER DIRECT DRIVE 120V/60HZ URN-300, URN-600, URN-1000
18* WC-3702 KIT, WATER PUMP SEAL RU’S USE ON WC-1000 ALL RU UNITS
19 WC-2605 CONNECTOR, 3/8 FLARE X 3/8 NPT ALL RU UNITS
20 WC-2608 SWIVEL, 3/8 TUBE x 3/8 NPT ALL RU UNITS
21 WC-2403 ELBOW, 3/8 FLARE x 3/8 NPT PLATED GEN USE ALL RU UNITS
23A WC-5808 DOOR, CONTROL BOX LOUVER, RU-225/600 RU-225, RU-600
23B WC-5807 DOOR, LOUVER ACB RU150/300 RU-150, RU-300
23C WC-5809 DOOR, CONTROL BOX LOUVER RU-1000
23D WC-87481 DOOR, CONTROL BOX URN-300
23E WC-87483 DOOR, CONTROL BOX URN-600
23F WC-87485 DOOR, CONTROL BOX URN-1000
22A WC-5322 TUBE ASSY, 1/4x20.00 WI W/NUTS RU-225, RU-600
22B WC-5321 TUBE ASSY, 1/4x17.00 WI W/NUTS RU-150, RU-300
RU/URN Series - Control Box - Parts List
1
UNITS BUILT BEFORE 1/29/13
2
UNITS BUILT 1/29/13 AND LATER
3
USE FOR POWER SWITCH, UNITS BUILT AFTER 1/29/13 ARE EQUIPPED WITH A SECOND TOGGLE SWITCH USED FOR
BATCH SELECTION
* RECOMMENDED PARTS TO STOCK
CONTINUED ON FOLLOWING PAGE
