ILLUSTRATED PARTS LIST IP69
RU AUTOMATIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 031022C
RU/URN Series - Control Box - Parts List (continued)
ITEM # PART # DESCRIPTION USED ON
22C WC-5323 TUBE ASSY, 1/4x26.00 WI W/NUTS RU-1000
23A WC-2929P FITTING, 1/2 NIPPLE/NUT PLATED ALL RU UNITS
23B WC-3045 FITTING, STRAIGHT 3/8-18 NPSM X 3/8 BARB X2 SS URN-300, URN-600, URN-1000
24A WC-5307 TUBE, 3/16 ID x 3/32W SILICONE ALL RU UNITS/ URN-300, URN-600, URN-1000
24B WC-5310 TUBE, 5/16 ID x 1/8W SILICONE URN-300, URN-600, URN-1000
25A WC-402 RELAY, HOLDING 120V COIL 10A OLDER RU UNITS EXCEPT RU-1000
1
25B WC-403 RELAY HOLDING 120V 3 POLE 6.6A RES.@240V OLDER RU-1000 UNITS
1
25C WC-417 RELAY, HOLDING 220V 2P 10A RU OLDER RU UNITS
26* WC-102 SWITCH, TOGGLE NON-LIT SPST 15A 125/6A 250VAC RESISTIVE ALL RU UNITS
3
27A* WC-5502-01 KIT, PROBE, ASSY WATER LEVEL W/HEX FITTING, O-RING & NUT ALL RU UNITS
27B WC-5528 PROBE, WATER LEVEL S.S. URN-300, URN-600, URN-1000
27C WC-2638 BUSHING, CONICAL .200 ID X.945 OD X .936 LG URN-300, URN-600, URN-1000
28A WC-405R-101K-120 KIT, AGITATION TIMER 120V RU-150,225,300,600,1000 DOMESTIC RU UNITS
28B WC-405R-101K-220 KIT, AGITATION TIMER 220V RU-150,225,300,600,1000 EXPORT RU UNITS
28C WC-405R-101 TIMER, AGITATION 90-260 VAC 30 SEC URN-300, URN-600, URN-1000
29A* WC-303 TERMINAL STRIP 12-S OLDER RU-150, RU-3000 UNITS
29B WC-304 TERMINAL STRIP, 14-S(RU1,6) OLDER RU-225, RU-600 UNITS
29C WC-302 TERMINAL STRIP, 6-S(GM,CRA) OLDER RU-1000 UNITS
30A WC-3737 KIT, BREW SWITCH 120V RU’S DOMESTIC RU UNITS
30B WC-3738 KIT, BREW SWITCH 220V RU RPL EXPORT RU UNITS
30C WC-122 SWITCH, BREW (GREEN) 120V NEON SPST 15A 250V URN-300, URN-600, URN-1000
31 WC-4608 SCREW, 8-32x1¼ PHIL RD HD 18-8 ALL RU UNITS
32A WC-10030 CONTROL MODULE,120/220V LIQUID LEVEL/BREW TIMER NEWER RU UNITS
5
32B* WC-10030K-RU KIT, CONTROL BOARD LIQUID LEVEL/BREW TIMER 120/240V RU NEWER RU UNITS
4
32C WC-608-101K KIT, LIQUID LEVEL CONTROL BOARD RETROFIT OLDER RU UNITS
1
33A WC-10030 CONTROL MODULE,120/220V LIQUID LEVEL/BREW TIMER NEWER RU UNITS
5
33B* WC-10030K-RU KIT, CONTROL BOARD LIQUID LEVEL/BREW TIMER 120/240V RU NEWER RU UNITS
4
33C WC-603-101K-RU KIT, RETROFIT TIMER, BREW SELECTOR 120V RU-300 W/ 1/2BB OLDER DOMESTIC RU UNITS
1
33D WC-622-101K-RU KIT, RETROFIT BREW TIMER FULL & 1/3 BATCH 220V RU OLD EXPORT UNITS AND RU-300 W/O HALF BATCH
1
34 WC-101 SWITCH, ON/OFF NON-LIT SPST MOMENTARY 3/6A 250/120V ALL RU UNITS
35 WC-100 SWITCH, RESET-STOP N.C.NON-LIT SP MOMENTARY 10/15A 250/120V ALL RU UNITS
36 WC-1501 FUSE, HOLDER ASSY W/5A FUSE ALL RU UNITS
37* WC-1500 FUSE, 5 AMP ALL RU UNITS
38 WC-2606 CONNECTOR, 1/2 FLARE X 1/2 NPT ALL RU UNITS
39A WC-2928P FITTING, 3/8 NIPPLE/NUT PLATED ALL RU UNITS
39B WC-3045 FITTING, STRAIGHT 3/8-18 NPSM X 3/8 BARB X2 SS URN-300, URN-600, URN-1000
40 WC-4403 SCREW, 6-32x3/8 PHIL ROUND HD ALL RU UNITS
41 WC-4616 SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD STAINLESS STEEL ALL RU UNITS
1
UNITS BUILT BEFORE 1/29/13
2
UNITS BUILT 1/29/13 AND LATER
3
USE FOR POWER SWITCH, UNITS BUILT AFTER 1/29/13 ARE EQUIPPED WITH A SECOND TOGGLE SWITCH USED FOR
BATCH SELECTION
4
UNITS BUILT BETWEEN 1/29/13 AND 5/04/18
5
UNITS BUILT 5/04/18 AND LATER
* RECOMMENDED PARTS TO STOCK
