Curtis RU Series User Manual

ILLUSTRATED PARTS LIST IP69
RU AUTOMATIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 0031022C
RU/URN Series - Faucet Assemblies - Parts List
ITEM # PART # DESCRIPTION USED ON
1 WC-2007 BRACKET, GAUGE GLASS GEM-3 ALL RU UNITS
2 WC-2003 CAP, PLUG VENTED 44 ALL RU UNITS
3A WC-2002K KIT, SHIELD CAP W/CLEAN OUT ALL RU UNITS
3B WC-2001 CAP, SHIELD W/VENT URN-300, URN-600, URN-1000
4 WC-2030 GLASS, GAUGE 13” RU-225, RU-600
5A WC-2108 GAUGE GLASS ASSEMBLY 13” USE ON RU-225 RU-225, RU-600
5B WC-2104 GAUGE GLASS ASSEMBLY 10” RU-150
5C WC-2105 GAUGE GLASS, ASSY 11” USE ON RU-150/300 RU-150, RU-300
5D WC-2113 GAUGE GLASS, ASSY 19” RU-1000
6A WC-2017 SHIELD, GAUGE GLASS 13” RU-225, RU-600
6B WC-2104 SHIELD, GAUGE GLASS 10” RU-150
6C WC-2014 SHIELD, 11” GAUGE GLASS RU-300
6D WC-2022 SHIELD, 19” GAUGE GLASS 1/8 NPT RU-1000
7 WC-1900 VALVE, GAUGE SHIELD SHUT-OFF 1/8 NPT ALL RU UNITS
8 WC-1800 FAUCET,”S” SERIES BLK LOCKING 1-1/32-14 UNS CURTIS ALL RU UNITS
9 WC-1805 SEAT CUP, “S” FAUCET USE ON WC-1800/B/LB/D/DL/L/WC-1803 ALL RU UNITS
10 WC-3705 KIT, FAUCET HANDLE S SERIES NONLOCK ALL RU URNS
11 WC-1906 C’ RING .917 X .760 X .090 TT-3 TC’S ALL RU UNITS
12 WC-1903 NUT, UNION SHANK WB-10/WB-10-60/WB-30-12 ALL RU UNITS
13 WC-2004K KIT, BASE GAUGE GLASS SHIELD ALL RU UNITS
14 WC-2006 WASHER, .188 ID X .188 THK BOTTOM GAUGE GLASS GEN USE ALL RU UNITS
15A WC-2028 GLASS, GAUGE 5/8” X 11” RU-150, RU-300
15B WC-2031 GLASS, GAUGE 14” RU-225, RU-600
15C WC-2029 GLASS, GAUGE 5/8” X 12” RU-300
15D WC-2037 GLASS, GAUGE 5/8” X 20” RU-1000
16A WC-2014 SHIELD, 11” GAUGE GLASS RU-150, RU-300
16B WC-2016 SHIELD, GAUGE GLASS 3/4D.X 12” RU-300
16C WC-2019 SHIELD, 14c” GAUGE GLASS RU-600
16D WC-2023 SHIELD, 20” GAUGE GLASS RU-1000
17A WC-2105 GAUGE GLASS, ASSY 11” USE ON RU-150 RU-150
17B WC-2109 GAUGE GLASS, ASSY 14” RU-225, RU-600
17C WC-2107 GAUGE GLASS, ASSY 12” SHORT WIN RU-300
17D WC-2114 GAUGE GLASS, ASSY 20” RU-1000
18 WC-2005 WASHER, SHIELD CAP 1/8” GEM-3/TC’S W/SG ALL RU UNITS
19 WC-2000 FITTING, AGITATION PLATED RU’S ALL RU UNITS
20 WC-3402 SPRING, RETURN “S”SERIES FAUCT ALL RU UNITS
21 WC-1813 WASHER, 1-1/8” OD ETHYLENE PROPYLENE RUBBER ALL RU UNITS
22 WC-1901AK KIT,FAUCET SHANK W/SHIELD BASE ALL RU UNITS
23 WC-1939 NUT, FLANGED TLS-2, GEM3, RU’S ALL RU UNITS
24 WC-5307 TUBE, 3/16 ID x 3/32W SILICONE GEN USE ALL RU UNITS
25 WC-4439 SCREW, 6-32x¼ PHIL PAN HD SS ALL RU UNITS
