MODEL: SHUTTLE™ 4
TYPE: ELECTRIC POW ERED PERSONNEL CARRIER
MODEL YEAR: 2012
Part No:. 618850
Precision Drive System™ (PDS): Factory programmable to application
Solid State continuously variable seperately ex cited speed controller
Eight, 6 Volt Deep C y cle
Dash mounted direction selector switch (Forw ard-Neutral-Rev erse)
Full torque, reduced speed rev erse
Anti-roll back, w alkaw ay braking and alarm
Inductiv e throttle sensor
Anti-stall motor protection
Diagnostic indicator
Regenerativ e ’Pedal Down’ and/or ‘Pedal U p’ braking
Factory selectable performance options
Battery Charger: Delta Q, 48 VDC. H 120/230 VAC 50/60 H z. U nderw riters Laboratories (U .L.) Listed, (C .S.A. Certified)
Motor: 48 v olt DC shunt wound, brazed armature, solid copper w indings. Intermittant H orsepower 18.1 hp (13.5 kW) at 1900 rpm (1hour)
Drive T rain: Direct motor shaft connected to transax le pinion shaft
Electrical System: 48 Volt DC, eight, 6 v olt deep cy cle storage batteries (107 minute, 225 amp-hour @ 20 hr. discharge rate)
T ransaxle: Differential w ith helical gears
Brakes: Dual rear w heel mechanical self-adjusting drum brakes. Automatic single point park brake release with self-compensating sy stem
Rear Ax le Ratio 14.7:1
Ov erall Length 133.5 in (339.0 cm)
Performance
Ov erall Width 46.5 in (119.0 cm)
Seating C apacity 4 Person
Ov erall H eight (N o C anopy ) 48.6 in (123.0 cm) (Top of steering w heel)
Dry Weight 720 lb (325 kg) (Without Batteries)
Ov erall H eight (With Canopy ) 72.0 in (183.0 cm)
Curb Weight 1210 lb (545 kg)
Wheel Base 93.5 in (237.0 cm)
Bed Load C apacity 400 lb (180 kg)
Front Wheel Track 34.2 in (86.7 cm)
Vehicle load capacity 1198 lb (540 kg)
Rear Wheel Track 38.0 in (97.0 cm)
Outside C learance C ircle 25.5 ft (7.8 m)
Gnd C learance @ Differential 4.3 in (11.0 cm)
Intersecting Aisle Clearance N/A
Cargo Box Width (inside) 42.5 in (108.0 cm)
Speed (Lev el Ground) 13 mph ± 0.5 mph (21 kph ± 0.8 kph)
Cargo Box Length (inside) 32.0 in (80.0 cm)
Steering & Suspension
Cargo Box Depth (inside) 11.5 in (29.0 cm)
Steering Self-compensating rack and pinion
Cargo Box C apacity 9 cu ft (.25 m3)
Front Suspension Leaf springs w ith hydraulic shock absorbers
Cargo Box material Wood Stake Sides
Rear Suspension Leaf springs w ith hydraulic shock absorbers
Vehicle Power
Serv ice Brake Rear w heel mechanical self-adjusting drum
Pow er Source 48 Volts DC
Parking Brake Self-compensating, single point engagement
Motor Type Shunt Wound
Front Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Continuous H orsepow er (kW) 2.5 hp (1.9 kW)
Rear Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Intermittent Horsepow er (kW) 18.1 hp (13.5 kW) @ 1900 rpm
Body & Chassis
Electrical Sy stem 48 Volt
Frame Welded steel. DuraShield™ pow der coat
Batteries (Qty , Ty pe) Eight, 6 Volt Deep C y cle
Body & Finish Injection molded TPO
Key or Pedal Start Pedal Start
Seat Pod Fiberglass & Gelcoat
Battery C harger 48 VDC Delta Q, 120/230 VAC , U L & C SA
Standard Color Champagne
Speed C ontroller 400 Amp Precision Driv e Sy stem (PDS)
Driv e Train Motor Shaft Direct Driv e
Transax le Differential w ith helical gears
Gear Selection Dash M ounted Forward-N eutral-Rev erse
Some items shown may be optional equipment
CONFIGURATION HIGHLIGHTS
PRODUCT SPECIFICATION
PRODUCT OVERVIEW
Dimensions
Specications are subject to change without notice
* Field installed accessories may require installation charges
Noise & Vibration
Sound pressure; continued A-weighted equal to or
less than 70 db(A)
Highest RMS value of weighted acceleration is 1.23 m/s
2
Highest RMS value of weighted acceleration is less than
2.5 m/s
2
The uncertainty of measurement is 0.69 m/s
2
Noise
Vibration, WBV
Vibration, HAV
