27
33: Repeat steps 27 - 32 until
the preferred level has been reached;
34: Climb to the next level through the
hatch; sit down in the hatch and mount
two knee rails on the 2
nd
rung and in the
hooks of the Mobile Guardrails for
permanent use. Now you are allowed to
stand on the platforms.
35: Place the four toe board brackets;
36: Place both end toe boards;
37: Place both longitudinal toe boards;
The above shows the assembly of the
freestanding mobile scaffold tower. If the
mobile scaffold tower is placed against the
façade (with a distance between façade and
platform not greater than 15 cm), the edge
protection (guardrail at hip height, knee
railing and toe board) on the façade side may
be omitted.
Attention: when building up a 3 m platform
height scaffolding, it is practical to add an
extra temporary platform to the assembly.
34
35
36
37
