23
§ Cd31 Initial factory setting (Settable range 0,1)
The function cannot be modified during revolution.
Set data to original factory setting.
Cd31=0 No change
Cd31=1 Initial factory setting, refer to function code table.
Note: After this function is active, content value returns to “0”, readable value is always “0”.
§ Cd32、33、34、35 DI1~DI4 external terminal function setting ( Settable range 0~14)
Setting external terminal by operator request, after external terminal put in , according to
Cd32 is DI1 function setting 、 Cd33 is DI2 function setting 、 Cd34 is DI3 function
setting 、 Cd35 is DI4 function setting.
0: No motion
1: Two kinds of speed order ﹝ 2DF ﹞
2: Three kinds of speed order ﹝ 3DF ﹞
3: Five kinds of speed order ﹝ 5DF ﹞
4: Two kinds of acceleration time ﹝ 2AC ﹞
5: Two kinds of deceleration time ﹝ 2DC ﹞
6: JOG
7: Inertia stop operation ﹝ MBS ﹞
8: Failure clear and Programable Logic Controller ﹝ PLC ﹞ time reset ﹝ RST ﹞
9: Switch analog input Al1, Al2
10: PID disable
11: PID Error Back
12: PID integral preservation
13: PID integral reset
14: PID soft start
Notice: When setting is 7 ﹝ MBS ﹞ or 8 ﹝ RST ﹞， directly set the external terminal short
to act without assume external operation pattern.
§ Cd36 Failure record clear (Settable range 0, 1)
Clear the failure record content of Code 32, 33, 34, and 35.
Cd36=0 No change
Cd36=1 All of the contents of data will be “nOnE”, display of “LoAd” after setting
Note: After this function is active, content value automatically returns to “0”, thus
readable value is always “0”.
