11. Function Code Table
NO Function Detail of Data Initial factory
setting
MODBUS
Address
0
Set frequency
0~240Hz 10 128
1 Frequency setting
procedure
0: Operation panel Cd00
1: External IN2 (0-10V)
2: External IN1 (4-20mA)
3: External IN2 (0-10V) hysteresis
4: External IN1 (4-20mA) hysteresis
5: Keypad VR
6: Multi-steps control
5 129
2 Select monitor display
data
0: Frequency (HZ)
1: Current (I)
2: RPM
3: DC Voltage (d)
4: Output AC Voltage (V)
5: External I/O status (E)
6: Temperature of PIM module (b)
7: MCK operation frequency feedback
8: Current step of multi-step function
9: Current time of multi-step function (min)
10: Motor vibration
0 130
3 Torque mode 0: Without auto boost
1: Auto boost
0 131
4 Operation command
0: Operation panel 1 3: 2 wire Operation 2
1: 2 wire Operation 1 4: 3 wire Operation 1
2: Operation panel 2 5: 3 wire Operation 2
0 132
5 V/F pattern
1-10 fixed Modes
11: Set by Cd57, Cd58
12: V/F 1.5 power curve
13: V/F 1.7 power curve
14: V/F square curve
2 133
6 Motor rated current 25~100% 100 134
7
Torque boost
0.0~15.0% 2 135
8
1
st
acceleration time
0.1~6000 (S/50HZ) 5 136
9
1
st
deceleration time
0.1~6000 (S/50HZ) 5 137
10
2
nd
acceleration time
0.1~6000 (S/50HZ) 10 138
11
2
nd
deceleration time
0.1~6000 (S/50HZ) 10 139
12
No.2 frequency
HZ 20 140
13
No.3 frequency
HZ 30 141
14
No.4 frequency
HZ 40 142
15
Jogging frequency
0.5HZ~30HZ 5 143
16
Start frequency
0.5HZ~60HZ 1 144
17
Upper limit frequency
10~240HZ 60 145
18
Lower limit frequency
0.5~100HZ 0 146
19
Jogging acceleration /
deceleration time
0.1~10 (S/50HZ) 1 147
20
Jump frequency 1
HZ 0 148
21
Jump frequency 2
HZ 0 149
22
Jump frequency width
0~6HZ 0 150
23
Braking mode 0: de-active
1: Active when stop
2: Active when start
3: Active both stop and start
0 151
24 DC braking frequency 1~60HZ 1 152
25
DC braking voltage
0~15 5 153
