D. Function Code
§
Cd00
Set frequency (Settable range 0.5~240 HZ)
There are 5 methods to change set frequency. Items A~C are methods of panel key
operation, items D-E are methods of external terminal input.
A. At display function, press READ and setting (Cd01=0)
B. Use PROG key to input data (Cd01=0)
C. Set VR on faceplate (Cd01=5)
D. Set external voltage (Cd01=1 or 3)
E. Set external voltage (Cd01=2 or 4)
Note:
1.
Set value should be in accordance with V/F slope (Cd05) and upper limit
frequency (Cd17).
Set by function key
A.
At display function, press READ and setting
(Cd01=0)
1 0. 0 0
READ
1 0. 0 0
1 0. 0 0
1 0. 0 0
▲
1 1. 0 0
Meanwhile the operation speed (Cd00) has been changed but not saved yet (power
cut off and supply again Cd00 still be10.00 )，press PROG/SET and save data.
