10. STANDARD SPECIFICATION
A. 200Vseries 1 phase
Motor rating (KW)
0.375＊
0.75
0.75＊
1.5
1.5＊
Model CT2001
ES-A37 ES-A75 ESe-A75 ES-1A5 ESe-1A5
Rated current (A)
2.4 4.2 4.2 6.2 6.2
Rated capacity (KVA)
0.96 1.8 1.8 2.9 2.9
Power supply
1
ψ
200~230V
±
10% 50HZ
±
5% or 1
ψ
200~230V
±
10% 60HZ
±
5%
Output voltage
3
∮
200V
、
220V
、
230V
Control method Sine P.W.M. Control
Frequency accuracy
Digital setting:
±
0.1% Analog setting:
±
0.5% (35
℃
)
Frequency resolution
Digital setting: 0.5
～
100Hz
→
0.01Hz 100Hz
～
240Hz
→
0.1Hz
Analog setting: (setting value/ 1000) Hz
Frequency range
0.5
～
240HZ
（
Initial frequency 0.5
～
30Hz
）
V/F ratio 10 patterns, or any V/F patterns
0.1
～
6000 sec
（
linear, two-step setting
）
Motor Braking No DB Transistor
DC Braking
DC Injection Braking
（
Setting mode, torque, time, active frequency
）
Standard feature Free run restart, jogging speed, upper/lower frequency limit setting, jump frequency setting,
8-step speed setting, frequency indicated output (DC0
～
10V), operation direction setting,
forward/reverse prohibit, voltage/current limit, data lock, EMI (with CT2000ESe only)
Relay Output Arrival with timer, failure, stop, acceleration, frequency equal, deceleration, over frequency
Frequency setting
Digital setting by keypad, or external analog signal
（
DC0
～
10V
，
DC4
～
20mA
）
Display 7-segment LED display: Frequency, current, voltage, setting value, function, failure status,
Temperature of PIM module
Protection Low voltage, over voltage, instantaneous power failure, over voltage stall, overload, over
current stall, instantaneous over current, acceleration over current, deceleration over
current, over heat.
Overload capacity
150% for 1 min, anti-time limit function, adjustable ( 25
～
100
﹪
)
Altitude Altitude 1,000m or lower, keep from corrosive gasses, liquid and dust
Ambient Temperature
-10
℃～
50
℃
(Non-condensing and not frozen)
Storage Temperature
-20
℃～
60
℃
Humidity
Relative between 45
﹪
to 90% (No condensing)
Cooling system Forced air-cooling
Weight (Kgs)
1.6
＊
1.6
1.6
＊
2.5
2.5
＊
Note 1: Braking resistor specification refer to page 6
＊
: Under development
