CUTES CT-2000ES - Page 48

48
37 Frequency gain setting 20~200% 100 165
38
Analog output calibrate
90~110% 100 166
39
Frequency command bias
0~250 125 167
40
No.5 Frequency
HZ 45 168
41
No.6 Frequency
HZ 50 169
42
No.7 Frequency
HZ 55 170
43
No.8 Frequency
HZ 60 171
44
Stop mode 0: Decelerate stop
1: Free run stop
2: Free run stop after deceleration time is
reached
0 172
45
Detect frequency level 0.5~240HZ
0.5 173
46
Speed multiplier 0.01~500
1 174
47
Relay 1 output select 0-7
1 175
48 Detec current level 40~150% 100 176
49
Lock data 0: Data change capable
1: Data change not capable
0 177
50
Software version Read only
X 178
51
Motor rated voltage
10-450
200V Series = 1
380V Series = 1.73
400V Series = 2
220 179
52
Auto voltage compensation
0.5%~15.0% 50 180
53
Motor slip differential boost
0.0~10.0% 0 181
54 External analog output
select
0: Display output frequency
1: Display output current
0 182
55 External analog input select
0: 0~10V normal pattern
1: 10~0V reverse pattern
0 183
56 Current stall preventive 10~200% 150 184
57 Max. Frequency FH setting 10~240HZ (FH) 60 185
Function Detail of Data Initial factory
setting
MODBUS
Address
26
DC braking time
1~60S 1 154
27
Operation direction setting
0: Both forward and reverse, stop before
changing direction
1: Both forward and reverse, no stop
required
2:Forward only
3: Reverse only
0 155
28
Restart in instantaneous
power failure / Free run start
0: Without / Without
1: With / Without
2: Without / With
3: With / With
0 156
29 Time 1~9000(sec) 5 157
30
“Stop” function at panel key
under the operation of
external sequence
0: Impossible
1: Possible
1 158
31
Initialize data
0: No change
1: Data at the time of shipment
0 159
32 DI1 External terminal setting
1 160
33 DI2 External terminal setting
2 161
34 DI31 External terminal
setting
3 162
35 DI4 External terminal setting
0: No motion
1: 2DF 5 ： 2DC 9: anlog switch
2: 3DF 6 ： JOG 10: PID disable
3: 5DF 7 ： MBS 11: PID inverting
4: 2AC 8 ： RST
4 163
36
Memory clear for fault
annunciation
1: Memory clear
0 164
