§ CE63 Integral gain (settable range 0.0~360.0 sec)
PID control and associated gain (I).
§ CE64 Differential gain (settable range 0.0~10.0 sec)
PID control and associated gain (D).
§ CE65 Integral output limit (settable range 0~100 %)
Set % a unit as output limit of the Integral control. 100% is maximum frequency output.
§ CE66 PID output limit (settable range 0~100 %)
Set % a unit as output limit of the PID control. 100% is maximum frequency output.
§ CE67 PID control target value 1 (settable range 0~100.0 %)
This parameter defines the percentage of target value when PID control.
§ CE68 PID output delay time （ settable range 0 ～ 10 sec ）
Set PID output delay time.
§ CE69 PID offset adjust （ settable range 0 ～ 200% ）
Set % a unit as PID output offset. 100%is central point.
§ CE70 PID output gain （ settable range 0 ～ 25 ）
Set enlarge magnification of PID output.
§ CE74 P control status selection （ settable range 0 ～ 1 ）
P 、 I 、 D controller is individual controller separately when setting value is 0.
P controller is in front of I, D controller when setting value is 1 (an error passes through
P controller then enter into I,D controller).
§ CE78 PID output characteristic selection （ settable range 0 ～ 1 ）
Set PID output inverse function, inverting when set 1.
§ CE79 PID control selection （ settable range 0 ～ 4 ）
0 : PID disable
1 : PID outpout is inverter frequency output, D control error.
2 : PID outpout is inverter frequency output, D control feedback.
3 : PID output is corrective value of inverter frequency output ( accede main frequency),
D control error.
4 : PID output is corrective value of inverter frequency output ( accede main frequency),
D control feedback 。
