4.3
Input and Output
4.3.1
S
etup
input and output types
Digital inputs types
Input
signals have two types,
EDGE_IN
(
edge trigg
er
ing
)
and LEVEL_IN
(
state triggering
)
.
ATTENTION:
T
he key
deferen
ce between Level and Edge is Level input has recovery
sms message
and Level input
can repeat alarm status sms notify by an interval.

24 Hours
I
f
enable this option
,
the digital input will execute alar
m
action (
send alarm sms, interlock etc) when it is
triggered, even RTU is in disarm status.
Level input alarm
Typical edge alarm
CWT501
6
Use
r
’s manual
14
www.mobq2000.com

Sound
Means
this
channel input
alarm event
can
cause
internal
buzzer and extend buzzer or siren action.

U
se digital input 1 as
arm
control
Enable
this option, RTU
is in arm mode if digital input 1 is opened, RTU is in disarm mode if digital input
1 is closed, so user can connect a button to switch mode for arm or disarm
ATTENTION:
U
se digital input
1 as arm control
you need select the type of input1 is
“
TO CLOSE
AL
ARM (LEVEL)
”
and delete the alarm/recover sms of input 1

C
ounter
En
able or disable this channel input as counter input which catch greater than 100ms plus.

C
ounter upload timer
Setup the counter GPRS upload interval

Counter upload only changed data
Autom
atic counter upload mode is a mode to Save GPRS, not report data if value not changed.
Attention
:
This
option is
valid
for the RTU
models that have
GPRS function.
Output types

Remember
outputs status
RTU
’
s outputs default status is
open;
it is
possible
closed during working.
After
restart,
the outputs will be
reset,
status is open.
I
f enable the option
,
output
can recover the status that bef
ore restart.
0
disable
1
relay drivable output
Drive relay,
drive electricity <0.2A
O
utput drive relay voltage Equal to input DC voltage
Output power: Drive voltage ≤35V, drive current ≤200mA
2
Buzzer
This
line
’
s actions will
synchronize
with
internal
buzzer.
3
SNAPSHOOT
This line wills
shortly action when any
alarm happens
.
4
SIREN
This line continuous drives
for 1
minute
by default.
A
n
d the
interval can be user define.
