4.3.5
CS
’
s DIN authority
T
his page can setup the
authority
of CS phone receive
digital
input alarm sms and alarm call
“
O
”
means this
c
s phone will receive related li
ne in sms,
“
X
”
means not.
Example:
T
his settings means CS0 don
’
t receive
input
0 alarm
CS1 don
’
t receive
input1
alarm sms.
CS3
don
’
t receive
input0
alarm sms.
CWT501
6
Use
r
’s manual
18
www.mobq2000.com
4.4
Setup Ain parameters
4.4.1
S
etup
Ain parameters
The analog input
is
designed to receive
0~20
mA
o
r 0~5V
signal from an analog
sensor
Y
ou can preset a high and a low level for every AD input, if current value is above the high level or below
the low level, RTU alarm.
You
also can send sms command to RTU to get current value.
E
xample:
RTU connect a temp
erature transmitter, it analog output range is 4
-
20 ma for monitor temperature range
is 0
℃
-
50
℃
, you want to get alarm and current temperature value when temperature is above 40
℃
or
below 10
℃
.

Urgent
I
f checked,
in any case, the RTU will execute alarm
action (
send alarm sms, interlock etc) when the AD
input is over normal range, even RTU is i
n disarm status.

Sound
alarm
Means
this line alarm event will cause
internal
buzzer and extend buzzer or siren action.

Upload step
Attention
:
This
option is
valid
for the RTU
models that have
GPRS function.
I
f
the
change of AD input is more than
“
upload
step
”
, RTU upload current value to server by GPRS.

M
inimum time
of twice
AD
alarm sms
(AINAS time)
After executed
an
alarm
action (
send alarm sms, interlock etc.)
When
AD
inputs
over normal range, in
the AINAS time RTU will not execute any alarm
action (
se
nd alarm sms, interlock etc.)
even AD inputs
are
over normal range frequently.
Th
e
purpose
of
setting
AINA
S time is
user will not receive many alarm
