Function description: The settings may be adjusted to the quality of the electricity in use.
e. Slew Rate: Also called Dynamic Frequency Tolerance. There are 5 different settings
(0.25,0.5,1,2,4 Hz/Sec). The default value is 4Hz/sec.
Function description: “Slew Rate” indicates the tolerance of a device in accepting frequency
variances. The lower “Slew Rate” results in less tolerance but better protection for the connected
loads.
f. Low Battery Shutdown Voltage: This function adjusts the EPS shutdown point according to the
battery voltage. The default setting is 10V (with load).
g. Mode Select: The standard mode (setting: 2) and the robust mode (setting: 1) are provided to
select. Using the generators is suggested to select the robust mode (setting: 1), and using the
computers is suggested to select the standard mode (setting: 2).
The settable items are sorted by unit as in the following table：
Step 3: Press and hold the toggle for 4 seconds. When the icons blink, the value of each item can be
changed by slightly pressing the toggle.
Step 4: To save the value and return to general mode, press and hold the toggle for 4 seconds.
Note: If the machine is left idle for over 30 seconds during setup, it will turn off the backlight
and return to general mode automatically.
Note: If user wants to return to general mode without saving changes, there are two methods:
1. Wait for the backlight to turn off
2. Press and hold the “Display” toggle for 10 seconds
Items Unit Icon Lit
Delay Time Min ON BAT
Charging Current % ON BAT
Nominal Output Voltage V NORMAL MODE
Static Frequency Tolerance % NORMAL MODE
Slew Rate % None
Low Battery Shutdown Voltage V ON BAT
Mode Select None None
