CYBEX Arc Trainer 750A Owners Manual And Service Manual

Cybex Arc Trainer 750A/750AT Owner’s Manual
15
Tools Required
Phillips screwdriver•
Torque wrench (in/lb)•
3/16” Allen wrench (supplied)•
7/32” Allen wrench (supplied)•
9/16” Open end wrench•
NOTE: The words “left” and “right” denote the user’s orientation.
Readandunderstandallinstructionsthoroughlybeforeassemblingunit.
Verifycorrectpackage.
Read box label to verify the model number and voltage (optional) match what was ordered.1.
Lift and remove cardboard sleeve surrounding unit.2.
Verify paint color matches what was ordered.3.
Verify correct voltage if option AC power kit is included.4.
Unpackandverify750Acontentsofcarton.
See 750A content listing and diagram below for 750A carton contents. 1.
Check off each item as found. See 2. Customer Service for contact information if any parts are
missing.
750A Contents
Item Quantity Part Number Description
1 1 Vanes Base with covers attached
1a 1 Vanes Console assembly (in box)
2a 1 750A-124 Handrail assembly
3 2 12090-322 Foot pad
4 1 740A-370 Tray, Main
5 1 740A-371 Tray, insert
6 1 NA Hardware pack
7 1 5750-4 Owner’s Manual
8 1 750A-402 Assembly poster
9 1 750A-391 Commercial Arc warranty sheet
10 1 750A-392 Consumer Arc warranty sheet

CYBEX Arc Trainer 750A Specifications

General

Brand	CYBEX
Model	Arc Trainer 750A
Category	Fitness Equipment
Language	English
