Cybex Arc Trainer 750A/750AT Owner’s Manual
73
Serial Number
The serial number is located on the unit as shown below.
Record serial number below for reference when calling Cybex Customer Service.
Serial Number________________________________
Serial Number location
Unit Serial Number, Product Name and Model Number•
This product may be produced under
one or more of the following patents
5,628,715 5,643,152 5,616,107
5,722,921 5,620,402 6,488,612
6,743,158 7,179,209 7,335,139
7,338,415 7,503,882 D480,773
D481,428 D486,535 D490,127
D490,128 D490,865 D491,237
D491,238 D497,190 6,033,350
7,727,128 7,717,831
1975 24th Ave SW Owatonna,MN. 55060 1-888-462-9239
Made in U.S.A.
MODEL# 8810-90
SERIAL# XXXXXXXXXXXXX
