CYBEX R Series

Qty.DescriptionItem
1Accessory Tray Top1
1Accessory Tray Base2
2
Screw, Pan Head Phillips, 8-16 x
.50"
3
Install Accessory Tray Bottom
1. Install the grommet to the frame.
Qty.DescriptionItem
1Grommet, Nylon, Long1
1Frame2
2. Install screws securing the accessory tray bottom to the accessory tray top using a Phillips screwdriver.
3. Install screw securing the accessory tray bottom to the frame using a Phillips screwdriver.
Qty.DescriptionItem
1Accessory Tray Bottom1
1Accessory Tray Top2
2Screw, Pan Head Phillips, 6 x .50"3
1
Screw, Pan Head Phillips, 8-16 x
.50"
4
Install Side Handles
1. Remove three locknuts from left support leg using 17mm open-end wrench and 6mm Allen wrench. Keep the
two spacers in place.
Page 22 of 47
