CyClone SC300 - Mounting Heights and Clearance; Wiring Installation

6 Cyclone Canopy Installation - English
mountIng HeIgHtS anD clearance
• ehoodshouldbeinstalledat28”minimumabovethe
cookingsurface.Ifpairingyourrangehoodwithagas
stoveminimummountingheightmustbe30”abovethe
cookingsurface.
WARNING
Minimum mountheightbetween rangetopto hood bottomshould
benolessthan28”forelectricorceramicstoves,andnolessthan30”
forgasstoves.emaximummountheightshouldbenomorethan
36”.ehoodmustbeinstalledatthecorrectmountingheight.Hoods
mounted too lowcouldresultinheatdamage.Hoodsmountedtoo
high, on the other hand, will beless eectiveandperformancemay
suer.
Checkyourceilingheightandthehoodheightmaximumbefore
youselectyourhood.
Hoodinstallationheightabovecooktopistheuser’spreference.
elowerthehoodisabovethecooktopthemoreecientitwill
beindrawingoutcookingodors,greaseandsmoke.
WIrIng InStallatIon
Grounding Instructions
isappliancemustbegrounded.
isapplianceisequippedwithacordhavingagroundingwireor
withaplughavinggroundingwire.egroundingwiremustbe
groundedproperlyinthejunctionboxortheplugmustbeplugged
intoanoutletthatisproperlyinstalledandgrounded.
1. Connectthepowerlinegroundwiretothegreengroundwire
suppliedwiththehood.
2. Connecttheblackpowerwiretotheblackwiresuppliedwith
thehood.
3. Connectthewhiteneutralwiretothewhitewiresuppliedwith
thehood.
Min: 3”
Max. 2 ¾”
Install the Electrical Power Supply
Positiontheoutletorjunctionboxwithinthespacecoveredbythe
ductcover.Placetheoutletorjunctionboxatamaximumdistance
of24”fromwherethecordexitsfromthehood.ecenterofthe
outletorjunctionboxshouldbepositionedat2¾”awayfromthe
centerofthefuturehoodlocation.Makesurethisdoesnotinterfere
withthemountingareaorwiththeductcover.
Min:
Ceramic/Electric
28”
Gas 30”
Max:
36”
36”
Green: Ground
White: Neutral
Black: Power
is appliance requires 120V 60Hz electrical supply and connection to an individual properly grounded branch circuit protected
by a circuit breaker or time delay fuse.
