AspectFT-Matrix MAX Area Controller Installation Guide (1/05/2015) 1-1
1.1 ASPECTFT-MATRIX MAX INTRODUCTION
Unpack your AspectFT-Matrix MAX Area Controller and inspect the contents for damaged or missing
items. Included in this package, you should find the following items:
. AspectFT-Matrix MAX Area Controller
. AspectFT-Matrix MAX Controlle
r Hardware Installation Guide (this document)
1.1.1 TOOLS REQUIRED
The following tools and supply may be required for installation:
. Small flat-bladed screwdriver - for field-bus and power connectors
. Drill - for mounting the product onto a wall
. Wire-strippers - for terminating EIA-485 connections
1.1.2 SAFETY PRECAUTIONS
NOTE
All equipment must be installed in accordance with
NEC and local codes. F
or more information on
local codes, please check state/local regulations in
your area.
CAUTION
To prevent damage to any of the electrical
components of this product and to ensure that it
c
ontinually operates, do not attempt to alter any
componentry.
SECTION 1
H
ARDWARE INSTALLATION
The following document provides general information relative to the hardware installation of the AspectFT-
Matrix MAX Area Controller hardware. Please read through this document carefully before proceeding with
the hardware installation process.

Cylon American Auto-Matrix Aspect Matrix MAX Specifications

General

Brand	Cylon
Model	American Auto-Matrix Aspect Matrix MAX
Category	Controller
Language	English
