SUBPCBPARTLIST
©CyrusAudioLtdJun2014 36 Cyrus6DAC,Cyrus8DACservicemanualIssue1
R912 SMD0805 10k MF1/8W1%
RP601 SMDCAT16 10kx4 MF1/16W5%
RP701 SMDCAT16 Notfitted IC701isAK4118A
SMDCAT16 100Rx4 MF1/16W5% IC701isAK4118E
RP702 SMDCAT16 100Rx4 MF1/16W5%
RP703 SMDCAT16 100Rx4 MF1/16W5% IC701isAK4118A
SMDCAT16 Notfitted IC701isAK4118E
RP801 SMDCAT16 100Rx4 MF1/16W5%
RP802 SMDCAT16 100Rx4 MF1/16W5%
RP901 SMDCAT16 10kx4 MF1/16W5%
RP902 SMDCAT16 10kx4 MF1/16W5%
RP903 SMDCAT16 100Rx4 MF1/16W5%
RP904 SMDCAT16 100Rx4 MF1/16W5%

Key:MF=metalfilm.NFR=non‐flammableresistor.MRS25=axialmetalfilmresistor
SMD‐0805=referstosurfacemountdevicesizeprofile0805
CAPACITORS

C601 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C602 SMD0805 1uF CP25V10% X7Rdielectric
C603 SMD0805 1uF CP25V10% X7Rdielectric
C604 SMD0805 1uF CP25V10% X7Rdielectric
C605 SMD0805 1uF CP25V10% X7Rdielectric
C606 SMD0805 1uF CP25V10% X7Rdielectric
C607 SMD0603 22nF CP50V10% X7Rdielectric
C608 SMD0603 22nF CP50V10% X7Rdielectric
C609 SMD0603 33pF CP50V5% NPOdielectric
C610 SMD0603 33pF CP50V5% NPOdielectric
C701 SMD0603 Notfitted
C702 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C703 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C704 SMD0603 100nF CP50V10% X7Rdielectric
C705 SMD0603 100nF CP50V10% X7Rdielectric
C706 SMD0603 100nF CP50V10% X7Rdielectric
C707 SMD0603 Notfitted
C708 SMD0603 Notfitted
C709 SMD0603 100nF CP50V10% X7Rdielectric
C710 SMD0603 100nF CP50V10% X7Rdielectric
C711 SMD0603 Notfitted
C712 SMD0805 470nF CP16V10% X7Rdielectric
C713 SMD0603 10pF CP50V5% NPOdielectric
C714 SMD0603 10pF CP50V5% NPOdielectric
C715 SMD0603 100nF CP50V10% X7Rdielectric
C716 SMD0603 100nF CP50V10% X7Rdielectric
C717 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C718 SMD0603 100nF CP50V10% X7Rdielectric
C801 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C802 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C803 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C804 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C805 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C806 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C807 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C808 SMD0603 100nF CP50V10% X7Rdielectric
C809 SMD0603 100nF CP50V10% X7Rdielectric
C810 SMD0603 100nF CP50V10% X7Rdielectric
C811 SMD0603 100nF CP50V10% X7Rdielectric
C812 SMD0603 100nF CP50V10% X7Rdielectric
C813 SMD0603 1nF CP50V5% NPOdielectric
