Cyrus CD T - Front Panel Parts Drawing; Front Panel Parts

FRONTPANELPARTSDRAWING
©CyrusAudioLtdJun2014 15 CDtServiceManualIssue1

17
59
:
57
i1)
a
b
c
d
e
h
fg


FrontPanelparts

1AM‐POWCP/ Standbyknobtrim
2AM‐PLENS/02 Powerlens
3AM‐LENSM/02 Remoteeyelens
4CD‐DISPW/ Displaywindow
5I6‐MBDIS/02 DisplayPCB
6
CD‐FACSE/B
CD‐FACSE/S
Frontfaciablack
Frontfaciasilver
7
I2‐FRONT/
I2‐FRONT/S
TechnicalMouldingblack
TechnicalMouldingsilver
8I2‐BEZEL/ CDslottrim
9AM‐BPPLT/V0Baseplate
10 AM‐BFOOT/Rubberfoot
