Cyrus CD T - Page 20

MAINPCBPARTLIST
©CyrusAudioLtdJun2014 17 CDtServiceManualIssue1
R714 SMD0603 1k5 TF1/10W1%
R715 SMD0603 100k TF1/10W1%
R716 SMD0603 47R TF1/10W1%
R717 SMD0603 47R TF1/10W1%
R718 SMD0603 10k TF1/10W1%
R719 SMD0603Notfitted
R720 SMD0603 0R TF1/10W1%
R802 SMD0603Notfitted
R804 SMD0603Notfitted
R805 SMD0603Notfitted
R811 SMD0603 330R TF1/10W1%
R813 SMD0603Notfitted
R814 SMD0603Notfitted
RP401 SMDCAY16 100R TF1/16W5%
RP402 SMDCAY16 1k TF1/16W5%
RP601 SMDCAY16Notfitted
RP603 SMDCAY16Notfitted
RP605 SMDCAY16Notfitted
RP609 SMDCAY16Notfitted
RP701 SMDCAY16 100R TF1/16W5%
RP702 SMDCAY16Notfitted
RP704 SMDCAY16 10k TF1/16W5%
RP705 SMDCAY16 100R TF1/16W5%
RP706 SMDCAY16Notfitted
CAPACITORS

C401 SMD0603 47p CP50V5%
C402 SMD0603 Notfitted
C403 SMD0603 22n CP25V10%
C404 SMD0603 22n CP25V10%
C405 SMD0603 22p CP50V5%
C406 SMD0603 22p CP50V5%
C407 SMD0603 Notfitted
C409 SMD0603 1n CP50V5%
C413 SMD0603 1u CP16V10%
C414 SMD0603 100pF CP50V5%
C415 SMD0603 100n CP25V10%
C416 SMD0603 1n CP50V5%
C417 SMD0603 100n CP25V10%
C501 RB.2/.5 10uF EL450V20%
C502 RB.2/.5 22uF EL400V20%
C503 RAD0.3/RAD0.4 100pFY1CAP Y1250V10%
Maybe100pFor2.2nF.Use
100pFforreplacement.
C504 RB.2/.4 330uF EL25V20%
C505 RB.2/.4 1200uF EL16V20%
C506 CAPSMD6.3 100uF EL25V20%
C507 CAPSMD6.3 220uF EL16V20%
C508 RB.2/.2 1uF EL50V20%
C509 RB.2/.2 1uF EL50V20%
C510 RAD0.2/RAD0.3 100n CP630V10%
C511 SMD0603 100n CP25V10%
C512 SMD0603 100n CP25V10%
C513 SMD0603 560p CP50V5%
