MAINPCBPARTLIST
©CyrusAudioLtdJun2014 20 CDtServiceManualIssue1
IC603 TSSOP14 Notfitted
IC604 TSSOP14 CD74HCT14PWR Hexinverter
IC605 SO‐16 Notfitted
IC606 TSSOP16 Notfitted
IC701 LQFP80 LPC1752FBD80 Microcontroller
VOLTAGEREGULATORS

VR801 SOT223 Notfitted
VR802 SOT223 LM1117MPX‐3.3 800mAvoltageregulator
FILTERS,INDUCTORS&CRYSTALS

L402 COIL_SMD_ 8x6 750050480 Pulsetransformer
L501 COIL‐ELF15 B82731M2132A030 6.8mH1.3A
L502 SMDLH 4.7uH SMDInductor
L503 SMDLH 4.7uH SMDInductor
L601 SMD1210 Notfitted
L602 SMD1210 Notfitted
X701 XTAL_GSX‐333 12.000MHz Crystal
XTAL601 XTAL‐SMD6 Notfitted
CONNECTORS&SOCKETS

CON601 CONLIF16T‐SM Notfitted
CON701 CONLIF25T‐SM 528082570 25wayLIFconnector
CON702 HEADER Notfitted
CON703 SIL_6W Notfitted
CON704 CONLIF12S
00‐8370‐127‐000‐
800+
12wayLIFconnector

CON801 2.8mmQC Notfitted
CON802 2.8mmQC Notfitted
CON803 3PINKKHEADER 0010321031 3pinheade r
CON804 CONMINIPWR6 Notfitted
CON805 RAD0.1 Notfitted
SK401 PHONOSNGL T6612AAAB Singlephono
SK402 PHONODUAL 12HP070HSG Dualphono
SK701 CON‐USB‐67803 651005136421 Mini‐USBconnector
OTHERPARTS

FS801 FUSE_UMZ 3404.2416.11 MiniaturefuseT1.0AL
RLY801 RELAY_G5NB Notfitted
SW701 TACT‐2‐RTANGLE Notfitted
SW702 TACT‐2‐RTANGLE KSS321GLFS Tactswitch
TOTX401 TOX179 GP1FAV51TK0F Opticaltransmitter
TX501 TX‐EF20 094‐931 SMPSTX

