14D-Link DAP-2310 User Manual
Section 2 - Installation
Getting Started
1. Connect the power adapter to the receptor on the rear panel of the DAP-2310 and then plug the other end of the
power adapter to a wall outlet or power strip. The power LED will turn ON to indicate proper operation.
2. Using an Ethernet cable, insert one end of the cable to the LAN port on the rear panel of the DAP-2310 and the other
end of the cable to a switch or router’s LAN port .
Note: You can also connect the DAP-2310 directly to the computer that will be used for conguration. The LAN LED
will illuminate to indicate a proper Ethernet connection.
3. Computers with 802.11 b/g/n wireless adapters can connect to the DAP-2310.
