D-Link DAP-1610 Quick Installation Guide

DAP-1610 Quick Installation Guide
SPECIFICATIONS
*
Hardware
Processor
· MT7628NN (575/580MHz)
RAM
· 64MB, DDR2
Flash
· 8MB, SPI
Interfaces
· 10/100BASE-TX LAN port
LEDs
· POWER/WPS
· Wi-Fi Signal Strength
Buttons
· WPS button to set up wireless connection
· RESET button to restore factory default settings
Antenna
· Two external non-detachable antennas (3dBi gain for
2.4GHz and 2dBi gain for 5GHz)
MIMO
· 2 x 2
Power connector
· CEE 7/16 plug for AC power supply
* The device features are subject to change without notice. For the latest versions of the
firmware and relevant documentation, visit www.dlink.ru.
20

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
