DAP-1610 Quick Installation Guide
Changing LAN IPv4 Address
This configuration step is available for the Access point, Repeater, and
Client modes.
1. Select the Automatic obtainment of IPv4 address to let DAP-1610
automatically obtain the LAN IPv4 address.
!
If the extender obtains the LAN IPv4 address automatically, then after
finishing the Wizard you can access the web-based interface using the
domain name (by default, dlinkap.local ) with a dot at the end.
If you want to manually assign the LAN IPv4 address for DAP-1610, do not
select the Automatic obtainment of IPv4 address checkbox and fill in
the IP address and Netmask fields and, if needed, the Gateway IP
address field. Make sure that the assigned address does not coincide with the
LAN IPv4 address of the router to which your device connects.
2. Click the NEXT button.
16

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
