D-Link DAP-1610 Quick Installation Guide

DAP-1610 Quick Installation Guide
Selecting Operation Mode
In order to connect your device to a wired router for adding a wireless network
to the existing local network, on the Device mode page, from the
Connection method list, select the Wired connection value. In this mode
you can change the LAN IP address, set your own settings for the wireless
network and set your own password for access to the web-based interface of
the device.
In order to connect your device to a wireless router for extending the range of
the existing wireless network, on the Device mode page, from the
Connection method list, select the Wi-Fi value. Then from the Work
mode list select the Repeater value. In this mode you can change the LAN
IP address, connect your device to another access point, set your own settings
for the wireless network, and set your own password for access to the web-
based interface of the device.
14

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
