D-Link DAP-1610 Quick Installation Guide

DAP-1610 Quick Installation Guide
Wireless Module Parameters
-58dBm at MCS7
-53dBm at MCS8
-51dBm at MCS9
Modulation schemes · 802.11a: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11g: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM with
OFDM
Physical Parameters
Dimensions (L x W x H)
· 51 x 49 x 98 mm (2 x 1.91 x 3.85 in)
Weight
· 120 g (0.26 lb)
Operating Environment
Power
· Input: 110 to 240 V AC, 50/60 Hz
Temperature
· Operating: from 0 to 40 °C
· Storage: from -20 to 70 °C
Humidity
· Operating: from 10% to 90% (non-condensing)
· Storage: from 5% to 90% (non-condensing)
24

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
