DAP-1665 Install Guide 13
Within one minute, press and hold the WPS button on the DAP-1665 for about one second. The
WPS LED will blink. When the Security LED becomes a solid green, it means wireless security
is enabled.
2
Installation
Wireless Client Mode
1
Plug the supplied power adapter into your DAP-1665 and connect it to the outlet or to a surge
protector. Press the Power switch on the back of the device. Verify that the Power LED is lit.
RESET
LAN
5V
1A
3
WPS Button
Press the WPS button on your existing wireless router or AP.
Note: Usually the WPS LED will start to blink. If necessary, check your router’s user manual for more
information.
