8D-Link DCS-2132L User Manual
Section 1: Product Overview
Front
Hardware Overview
1 Status LED
Indicates the camera's current status
2 WPS Status LED Indicates the WPS connection status of the camera
3 Infrared LED
Used to illuminate the camera's eld of view at night
4 PIR Sensor
Passive Infrared sensor for motion detection
5 Camera Lens Records video of the surrounding area
6 Microphone Records audio from the surrounding area
7
ICR Sensor
The IR-Cut Removable sensor monitors lighting conditions and switches between
color and infrared accordingly
8
Speaker
Audio output
1
2
3
4
5
6
8
7
