Location LED Color Status Description
LED Per
10/100/1000
Mbps Port
Link/Act/Speed
Mode
Green Light on (Solid) When there is a connection (or link) to a
1000 Mbps Ethernet device on any of the
ports
Light blinking When there is reception or transmission
of data occurring at 1000 Mbps
Amber Light on (Solid) When there is a connection (or link) to a
10/100 Mbps Ethernet device on any of
the ports
Light blinking
When there is reception or transmission
of data occurring at 10/100 Mbps
Off Light off Link down or no link
LED Per 10
Gbps Port
Link/Act/Speed
Mode
Green Light on (Solid) When there is a connection (or link) to a
10 Gbps Ethernet device on any of the
ports
Light blinking When there is reception or transmission
of data occurring at 10 Gbps
Amber Light on (Solid) When there is a connection (or link) to a
10/100/1000 Mbps Ethernet device on
any of the ports
Light blinking When there is reception or transmission
of data occurring at 10/100/1000 Mbps
Off Light off Link down or no link
LED per SFP
Port
Link/Act Green Light on (Solid) When there is a connection (or link) to a
1000 Mbps Ethernet device on any of the
ports
Light blinking When there is reception or transmission
of data occurring at 1000 Mbps
Amber Light on (Solid) When there is a connection (or link) to a
100 Mbps Ethernet device on any of the
ports
Light blinking When there is reception or transmission
of data occurring at 100 Mbps
Off Light off Link down or no link
LED per SFP+
Port
Link/Act Green Light on (Solid) When there is a connection (or link) to a
10 Gbps Ethernet device on any of the
ports
Light blinking When there is reception or transmission
of data occurring at a 10 Gbps port
Amber Light on (Solid) When there is a connection (or link) to a
1000 Mbps Ethernet device on any of the
ports
Light blinking When there is reception or transmission
of data occurring at a 1000 Mbps port
Off Light off Link down or no link
