11D-Link DHP-W307AV User Manual
Section 2 - Installation
Hardware Installation
SET-UP DHP-306AV
Plug the DHP-306AV into an AC wall outlet close to your router and connect the included CAT5 Ethernet
cable to the Ethernet jack of the DHP-306AV to your router as seen in Room A.
Simple Connection
Button
Reset Button
Room A
DIR-655 DHP-306AV
DHP-W306AV
Room B
