Section 1 - Product Overview
Hardware Overview
DHP-W306AV LEDs
Power LED
• Solid. The device is receiving
electrical power.
• Blinking. The device is setting
itself up after reset or security
button was pressed or power
saving mode enabled.
• Off. The device is not receiving
electrical power.
Wireless LED
• Solid. The device is connected to a
Wireless network.
• Blinking. The device is transmitting
data.
Ethernet LED
• Solid. The Ethernet port is linked but
there is no data trafc.
• Blinking. The device is transmitting
data.
• Off. There is no Ethernet connection.
Powerline LED
• Solid. The device is connected to a
Powerline network.
• Blinking. The device is transmitting data.
• Off. The device has not found any other
compatible Powerline devices using the
same encryption key.
