D-Link DIR-605 User Manual
Section 3 - Conguration
&OUFSB OBNFGPSUIF SVMF:PVNBZ TFMFDUB
pre-defined application from the drop-down
menu and click <<.
This is the port used to trigger the application. It
can be either a single port or a range of ports.
Select the protocol of the trigger port (TCP,
UDP, or Both).
This is the port number on the Internet side that
XJMMCF VTFEUP BDDFTTUIF BQQMJDBUJPO:PVNBZ
EFGJOFB TJOHMFQPSU PSB SBOHFPG QPSUT:PV
can use a comma to add multiple ports or port
ranges.
Select the protocol of the firewall port (TCP,
UDP, or Both).
Name:
Trigger:
Trac Type:
Firewall:
Trac Type:
Application Rules
Some applications require multiple connections, such as Internet gaming, video conferencing, Internet telephony and others.
These applications have diculties working through NAT (Network Address Translation). Special Applications makes some of
these applications work with the DIR-605. If you need to run applications that require multiple connections, specify the port
normally associated with an application in the “Trigger Port” eld, select the protocol type as TCP or UDP, then enter the rewall
(public) ports associated with the trigger port to open them for inbound trac.
The DIR-605 provides some predened applications in the table on the bottom of the web page. Select the application you
want to use and enable it.
