DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Parameter Description
VLAN ID
An identifier of the VLAN to which this group of ports will be
assigned.
Ports
Port
From the list, select an available value (a physical port of the router,
the wireless interface) to assign it to this group. The port will be
displayed in the table at the bottom of the page.
QoS
A priority tag for the traffic transmitted through the port highlighted
in the table at the bottom of the page.
Tag
Select a value for the port highlighted in the table at the bottom of
the page:
• tagged,
• untagged.
Click the Save changes button.
Click the Delete port button to delete the port highlighted in the table at the bottom of the page.
Click the Delete VLAN button to delete this group of ports form the system.
!
For further use of groups of ports for VLAN it is required to save the changed settings to
the non-volatile memory of the router and reboot it (click the Save&Reboot line in the
top-page menu displayed when the mouse pointer is over the System caption).
Page 149 of 197
