5D-Link DIR-655 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and hubs.
2 Internet Port The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable or DSL modem.
3 USB Connect a USB ash drive or printer.
4 On/O Button Pressing the on/o button toggles power to the router.
5 Reset Pressing the Reset button restores the router to its original factory default settings.
6 Power Receptor Receptor for the supplied power adapter.
1
2 3
6
5
4
