6D-Link DIR-825+ User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 WPS Button Press to start the WPS process and automatically create a secure connection to a WPS client.
2 Reset Button (on bottom) Insert a paperclip in the hole, wait for 10 seconds, and release to reset the router to default settings.
3 Wi-Fi Button Press to enable or disable the wireless networks.
4 Gigabit LAN Ports (1-4) Connect Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
5 Gigabit Internet Port Using an Ethernet cable, connect your broadband modem to this port.
6 USB Port Connect a USB ash drive to share on your network.
7 Power Connector Connector for the supplied power adapter.
8 Power Button Press the power button to power the device on and o.
