D-Link DIR-825+ User Manual

157D-Link DIR-825+ User Manual
Section 5 - Connecting to a Wireless Network
WPA/WPA2
It is recommended that you enable wireless security (WPA/WPA2) on your wireless router or access point before conguring
your wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.
2. Highlight the Wi-Fi name (SSID) you would like to connect to and click
Connect.
1. Open the Windows Vista® Wireless Utility by right-clicking on the wireless
computer icon in your system tray (lower right corner of screen). Select
Connect to a network.

D-Link DIR-825+ Specifications

General

Frequency Bands	2.4 GHz, 5 GHz
LAN Ports	4 x 10/100/1000 Mbps Gigabit Ethernet
WAN Ports	1 x 10/100/1000 Mbps Gigabit Ethernet
USB Ports	1 x USB 2.0
Security	WPA, WPA2, WPS
Firewall	SPI, NAT
VPN Support	PPTP, L2TP, IPSec
Wireless Speed	Up to 300 Mbps (2.4 GHz), Up to 867 Mbps (5 GHz)
