37D-Link DIR-825+ User Manual
Section 3 - Conguration
Manual Internet Connection Setup
WANINTERNET
DIR-825+
SETUP
WAN
Use this section to congure your Internet Connection type. There are several connection types to choose from: Static IP, DHCP, PPPoE,
PPTP, L2TP, DS-Lite and Russia PPPOE. If you are unsure of your connection method, please contact your Internet Service Provider.
Note : If using the PPPoE option, you will need to remove or disable any PPPoE client software on your computers.
Save Settings Don’t Save Settings
INTERNET CONNECTION TYPE
Choose the mode to be used by the router to connect to the Internet.
My Internet Connection is :
Static IP
▼
Dynamic IP (DHCP)
PPPoE (Username / Password)
PPTP (Username / Password)
L2TP (Username / Password)
RUSSIA PPPoE (Username / Password)
DS-Lite
Click Manual Internet Setup on from the Internet menu to congure your Internet
connection manually. This section is only recommended for advanced users. It is
recommended to use the Setup Wizard to set up your Internet connection.
My Internet
Connection is:
Select the Internet Connection protocol from the dropdown menu
your ISP uses. The options are Static IP, DHCP, PPPoE, PPTP, L2TP,
and DS-Lite.
INTERNET CONNECTION TYPE
For Static IP setup help refer to page 38.
For Dynamic IP (DHCP) setup help refer to page 39.
For PPPoE (Username / Password) setup help refer to page 40.
For PPTP (Username / Password) setup help refer to page 42.
For L2TP (Username / Password) setup help refer to page 44.
For RUSSIA PPPoE (Username / Password) setup help refer to page page 46.
For DS-Lite setup help refer to page 48.
